Circular Grinding
Cylindrical grinding is a machining method used for shaping workpieces, where a rotating grinding wheel is employed to shape the workpiece and create a smooth surface. This technique finds application in various industries, including the automotive, aerospace, mechanical engineering, and medical sectors.
Clamping technology plays a vital role in cylindrical grinding, as the workpiece needs to be securely and precisely held to allow for high-quality processing. There are various types of clamping systems that can be used depending on the workpiece's shape and size. SwissChuck specializes in precision clamping technology for the cylindrical grinding process. SwissChuck's clamping solutions offer absolute precision in repeat clamping and are hermetically sealed, lubricated, and designed for maximum durability, ensuring extended tool life.
SAP for the KCHP
SAP Clamping ring for grinding between centers
KFHP
Precision power chucks for large workpieces
KCHP / VKCHP
Precision power chuck for cylindrical grinding machines
VMCHP
Precision diaphragm chuck with axial clamping
TGC / FTGC
Tool chucks TGC for the automated production
OVEKA
Precision compensating chuck for demanding shaft-type workpieces
OVEKAV
Reactable compensating chucks
FLD
Twist finger chuck for axial clamping of gears, for example
Triton
Precision power chuck for soft and hard-turning operations
D1 - D3
Multi-blade Mandrel D1 - D3
LZK / LZK-S
Multi-blade Collet Chuck LZK-S
PZLHM
Compressed air – Hollow clamping cylinders
Face drivers & counterpoints
Face drivers with matching spare parts and accessories
Magnetic Chuck
With radial or parallel pole pitch
